Also Offered — Custom Fabrication
Vent Bag Protectors, Pump Shields, Tag Boards, Slotted Pipe, Hot-Butt Welder — and one-off custom HDPE / PU parts. Send drawings or photos — we fabricate. (Grout Mixing Tanks now have their own page under Water.)
At a glance
Specifications.
Why this product
Engineered for working sites.
— Vent Bag Protectors —
2 mm HDPE sheeting, minimum 7 m length, eyelets every 500 mm. 2.3 m wide variant suits 1065 and 1200 mm vent bag; 3.0 m wide variant suits 1400 mm vent bag.
— Pump Shields —
8 kW pump shield: 690 × 640 mm, 15 kg. 20 kW pump shield: 1010 × 630 mm, 20 kg. 2-Year warranty on every shield.
— Tag Boards & Mobile Stands —
1300 × 1000 × 500 mm, 18 kg, with document sleeves and weather-proof seal. Mobile-stand variant available.
— Slotted Pipe (up-hole emulsion) —
90 × 3000 mm and 79 × 1800 mm standard sizes.
— Hotbutt M110 12-Volt Welder —
Standard, Stainless Steel and Stainless-clamp variants. Body 500 × 300 × 150 mm, 11.5 kg. Dies for 50 / 63 / 75 / 90 / 110 mm pipe.
— Other custom HDPE / PU parts —
HDPE under-seat protectors, conductor clamps, storage cabinets, wash stations, rope bins, riser tool boxes (heavy-duty 20 mm material), Blast PED holders (650 × 250 mm, 4 kg) — built to drawing. We work across the HDPE polymer range (HDPE primary, LLDPE, PP, PU, polycarbonate) using rotational moulding, PU casting, welding (butt / socket / friction / extrusion), CNC routing and 4 m sheet bending in-house.
Sizes
Pick a size — or spec your own.
| Size | OD | Length | Weight | Notes |
|---|---|---|---|---|
| Vent Bag Protector — 2.3 m | — | — | — | 2.3 m wide · 7 m+ length · eyelets every 500 mm · suits 1065 / 1200 |
| Vent Bag Protector — 3.0 m | — | — | — | 3.0 m wide · suits 1400 mm vent bag |
| Pump Shield — 8 kW | — | — | — | 690 × 640 mm · 15 kg |
| Pump Shield — 20 kW | — | — | — | 1010 × 630 mm · 20 kg |
| Tag Board — Standard | — | — | — | 1300 × 1000 × 500 mm · 18 kg · weather-proof |
| Slotted Pipe — 90 × 3000 mm | — | — | — | Up-hole emulsion |
| Slotted Pipe — 79 × 1800 mm | — | — | — | Up-hole emulsion |
| Custom | — | — | — | One-off HDPE / PU parts to drawing |
Ready to specify also offered — custom fabrication?
Send your site details and requirements — our engineering team will scope and quote.
